> 25 years Warranty
> Highest conversion efficiency of 17%
> Anti-reflective and anti-soiling surface power
loss from dirt and dust
> Excellent mechanical load resistance
> PID Resistant,High salt and ammonia resistance
Overview
Quick Details
- Place of Origin:
-
Anhui, China
- Brand Name:
-
Bluesun/OEM
- Model Number:
-
BSM10K-ON
- Application:
-
Home, Commercial, Industrial
- Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
- Battery Type:
-
NONE
- Controller Type:
-
MPPT, PWM, MPPT
- Mounting Type:
-
Ground Mounting, Roof Mounting, Carport Mounting, BIPV Mounting, Ground / Roof
- Load Power (W):
-
10KW
- Output Voltage (V):
-
110V 220V
- Output Frequency:
-
50/60HZ
- Work Time (h):
-
24 Hours
- Certificate:
-
CE TUV ETL
- Product name:
-
Solar Power System 10Kw and 380V AC Grid Tied Solar Power System
- Min. Space Needed:
-
103 Square meters
- Daily Generation:
-
60KWH (PSH=5)
- Optional Part:
-
Storage battery
- Serve Life:
-
10--15 years
- Safety Class:
-
Class A
- Complete Set:
-
Yes
- Installation Manual:
-
Yes
- Technical Support:
-
Yes
Supply Ability
- Supply Ability:
- 8000000 Watt/Watts per Day
Packaging & Delivery
- Packaging Details
- In well protected carton with pallet
- Port
- ShangI/Ningbo
- Picture Example:
-
- Lead Time :
-
Quantity(Watts) 1 - 10000000 >10000000 Est. Time(days) 3 To be negotiated
Product Description
Grid-tied, on-grid, utility-interactive, grid intertie and grid back feeding are all terms used to describe the same concept – a solar system that is connected to the utility power grid.
Residential
Commercial
Industrial
10KW Grid-tied Solar Power System Components List | ||||||
Item | Model | Description | Quantity | |||
1 | Solar Panel | Mono 390w solar panel | 26 pcs | |||
2 | Grid-tied Inverter | 10kw | 1 pc | |||
3 | Wi-Fi Module | Monitoring device | 1 pc | |||
4 | Mounting Support | Roof/Ground | 1 set | |||
5 | Cable | 4mm² PV cable | 200 m | |||
6 | Connector | Solar connector | 10 pairs | |||
7 | Tools Bag | 1 set | ||||
12KW Grid-tied Solar Power System Components List | ||||||
Item | Model | Description | Quantity | |||
1 | Solar Panel | Mono 390w solar panel | 32 pcs | |||
2 | Grid-tied Inverter | 12kw | 1 pc | |||
3 | Wi-Fi Module | Monitoring device | 1 pc | |||
4 | Mounting Support | Roof/Ground | 1 set | |||
5 | Cable | 4mm² PV cable | 200 m | |||
6 | Connector | Solar connector | 10 pairs | |||
7 | Tools Bag | Solar Installation tools | 1 set | |||
15KW Grid-tied Solar Power System Components List | ||||||
Item | Model | Description | Quantity | |||
1 | Solar Panel | Mono 390w solar panel | 40 pcs | |||
2 | Grid-tied Inverter | 15kw | 1 pc | |||
3 | Wi-Fi Module | Monitoring device | 1 pc | |||
4 | Mounting Support | Roof/Ground | 1 set | |||
5 | Cable | 4mm² PV cable | 200 m | |||
6 | Connector | Solar connector | 10 pairs | |||
7 | Tools Bag | Solar Installation tools | 1 set | |||
Configuration detail
Solar Panels
Grid-tied Inverters
> 5 years standard warranty
> Max.Efficiency 99.6%,European efficiency 99%
> Integrated DC switch for added safety protection
> Power factor continuously adjustable
>Transformer-less design and high power density,
off lighter and more convenient installation
> Flexible communication connection, support RF WIFI
Mounting support
> Residential Roof(Pitched Roof)
> Commercial Roof(Flat roof&workshop roof)
> Ground Solar Mounting system
> Vertical wall solar mounting system
> All aluminum structure solar mounting system
> Car parking solar mounting system
Accessories
> PV Cable 4mm2 6mm2 10mm2, etc
> AC Cable
> DC/AC Switches
> DC/AC Breakers
> Monitoring device
> AC/DC Combiner box
> Tools bag
Advantages of Grid-Tied Systems
1. Save more money with net metering
Your solar panels will often generate more electricity than what you are capable of consuming. With net metering, homeowners can put this excess electricity onto the utility grid instead of storing it themselves with batteries.
2. The utility grid is a virtual battery
The electric power grid is in many ways also a battery, without the need for maintenance or replacements, and with much better efficiency rates. In other words, more electricity goes to waste with conventional battery systems.
Packing & Delivery
By sea | Delivery from Shanghai or Ningbo seaport | ||||
By air | Departure from Shanghai Pudong Airport | ||||
By express | TNT / DHL | ||||
Project
250KW on grid solar project in Malta, EU
60KW on grid solar project in Guatemala, South America
1.2MW solar power plant in Ecuador, South America
144KW on grid solar project in California, USA
150KW on grid solar project in Japan
Our Company
History:
From 1983, first for silicon business, 2004 beginning produce solar cell, solar panel, capacity 50MW per year
Capacity:
Full automatic production line, all machine import from Germany. Now capacity 500MW per year
International:
400MW export to more than 80 countries, EPC company in Germany, Italy, USA and Canada
World Partner:
More than 20 famous international famous company partner in the world, solar city, Solar world, Q-Cell, Tesla...
Office&Warehouse:
More than 4 office in the world, Germany, USA, Brazil, Canada, Ukraine, Los Angeles & Rotterdam warehouse
Service:
100 international sales, English, Spain, France Language. We support all time all language service.
