Bluesun Solar Panel System 10KW Grid Tied Home Solar Power System 10KW Solar Energy System

  • 10000 - 49999 Watts
    $0.70
  • 50000 - 99999 Watts
    $0.60
  • 100000 - 299999 Watts
    $0.50
  • >=300000 Watts
    $0.40
Solar Power (W):
10KW/10000W
System Type:
On-Grid Solar System
Lead Time:
Quantity(Watts) 1 - 10 11 - 50 51 - 100 >100
Est. Time(days) 5 7 15 Negotiable
Customization:
Customized logo (Min. Order: 30000 Watts)
Customized packaging (Min. Order: 30000 Watts)

More

Graphic customization (Min. Order: 30000 Watts) Less
Samples:
$1.22 /Watt | 1 Watt (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Anhui, China
Brand Name:
Bluesun/OEM
Model Number:
BSM10K-ON
Battery Type:
NONE
Certificate:
CE/CEC/ETL/TUV
Output Frequency:
50/60hz
Application:
HOME, Commercial, Industrial
Work Time (h):
10 Hours
Mounting Type:
Ground Mounting, Roof Mounting, Carport Mounting, Ground or roof Mounting
Output Voltage (V):
110/120/208/240/277/480V
Load Power (W):
no limit
Controller Type:
MPPT
Solar Panel Type:
Monocrystalline Silicon, Polycrystalline Silicon
Grid Type:
10KW Grid Tied Home Solar Power System
Daily Generation:
50KWH (PSH=5)
Min. Space Needed:
60 Square meters
Serve Life:
25 years
Optional Part:
Storage battery
Safety Class:
Class A
Complete Set:
10 kw solar energy systems
Technical Support:
Solar System Installation Vedio
Installation Manual:
Yes
Supply Ability
Supply Ability:
100000 Watt/Watts per Week
Packaging & Delivery
Packaging Details
carton and pallet
Port
Ningbo or Shanghai Sea Port
Picture Example:
package-img
package-img
Lead Time :
Quantity(Watts) 1 - 10 11 - 50 51 - 100 >100
Est. Time(days) 5 7 15 To be negotiated
Video Description
Product Description

Grid-tied, on-grid, utility-interactive, grid intertie and grid back feeding are all terms used to describe the same concept – a solar system that is connected to the utility power grid.

Configuration detail
10KW Grid-tied Solar Power System Components List
Item
Model
Description
Quantity
1
Solar Panel
Mono 295W or Poly 280W solar panel
40 pieces
2
Grid-tied Inverter
10000W EU standard or US standard
1 piece
3
Wi-Fi Module
Monitoring device
1 piece
4
Mounting Support
Pitched / flat roof, ground
1 set
5
Cable
Single-core PV cable
300 meters
6
Connector
MC4 connector
4 pairs
7
Tools Bag
5 kinds of PV installation tools
1 bag
More details please send inquiry to us

Solar Panels

> 25 years Warranty
> Highest conversion efficiency of 17%
> Anti-reflective and anti-soiling surface power
loss from dirt and dust
> Excellent mechanical load resistance
> PID Resistant,High salt and ammonia resistance

Grid-tied Inverters

> 5 years standard warranty
> Max.Efficiency 99.6%,European efficiency 99%
> Integrated DC switch for added safety protection
> Power factor continuously adjustable
>Transformer-less design and high power density,
off lighter and more convenient installation
> Flexible communication connection, support RF WIFI

Mounting support

> Residential Roof(Pitched Roof)
> Commercial Roof(Flat roof&workshop roof)
> Ground Solar Mounting system
> Vertical wall solar mounting system
> All aluminum structure solar mounting system
> Car parking solar mounting system

Accessories

> PV Cable 4mm2 6mm2 10mm2, etc

> AC Cable
> DC/AC Switches

> DC/AC Breakers
> Monitoring device
> AC/DC Combiner box

> Tools bag

Packing & Delivery
By sea
Delivery from Shanghai or Ningbo seaport
By air
Departure from Shanghai Pudong Airport
By express
TNT / DHL
Project
Global Exhibitions
Our Company
Payment






Payment Term



T/T
EXW

30% T/T in advance, paid the balance before shipment
FOB
CFR(C&F)

30% T/T in advance, paid the balance against copy of B/L
CIF
L/C
L/C amount above 50,000 usd, we can accept L/C at sight
Paypal

Amount lower than 5000usd
West Union
Delivery Time
7~10days after receiving payment for one container

We welcome use Trade Assurance, you'll enjoy:
100% product quality protection
100% on-time shipment protection
100% payment protection for your covered amount
